SAPPHIRE Announces New Family of Compact AMD Ryzen™ Embedded Processor Based Motherboards at Embedded World 2020

Verfasst vonpipin

SAPPHIRE Tech­no­lo­gy builds on the repu­ta­ti­on and strength of its embedded sys­tems busi­ness divi­si­on by announ­cing a new series of embedded mother­boards with a com­pact foot­print that deli­ver impro­ved levels of per­for­mance, fea­tures and sta­bi­li­ty to cus­to­mers. Powered by the latest AMD Ryzen™ Embedded Pro­ces­sor which fea­ture the AMD Rade­onTM “Vega” gra­phics com­bi­ned with the high-per­for­mance “Zen” CPU, the BP-FP5 and NP-FP5 embedded plat­forms pro­vi­de a sta­ble balan­ce of low power con­sump­ti­on and opti­mi­zed per­for­mance for the embedded markets.

Accor­ding to Paul Smith, Direc­tor of SAPPHIRE’s Embedded Busi­ness Divi­si­on, “the ver­sa­ti­le and effec­ti­ve design of the­se boards with low power com­pu­te and high-reso­lu­ti­on mul­ti­me­dia dis­play capa­bi­li­ty make them per­fect for a wide varie­ty of indus­try appli­ca­ti­ons in the Embedded space such as indus­tri­al PC, inter­ac­ti­ve digi­tal signage, thin cli­ents and POS terminals”.

SAPPHIRE BP-FP5V

SAPPHIRE Excel­lence
SAPPHIRE’s BP-FP5 and NP-FP5 embedded boards have a com­pact foot­print of 4 inches x 4 inches and fea­ture up to 32 GB dual-chan­nel DDR4 (2400 MHz) SODIMM memo­ry as well as expan­si­on inter­faces inclu­ding M.2 sockets for WiFi and SSD modu­les. The BP-FP5 sup­ports up to three inde­pen­dent 4K dis­plays with on board 2 x Dis­play­Po­rt (DP) and 1 x HDMI 2.0 and I/O con­nec­ti­vi­ty of 5 x USB ports. The NP-FP5 sup­ports up to two inde­pen­dent 4K dis­plays with on board 2x mini-Dis­play­Po­rt (DP) and I/O con­nec­ti­vi­ty of 5 x USB ports. Moreo­ver, the BP-FP5 and NP-FP5 boards ope­ra­te with maxi­mum APU ther­mal design power (TDP) of 25W whilst deli­ve­ring out­stan­ding com­pu­te and gra­phics performance.



SAPPHIRE NP-FP5V

Powered by AMD Ryzen™ Embedded Processor
The BP-FP5 and NP-FP5 sup­port the latest AMD Ryzen Embedded V1000 and R1000 Pro­ces­sors that pro­vi­de ultra-high per­for­mance to embedded mar­kets by com­bi­ning the powerful per­for­mance of the pio­nee­ring “Zen” CPU and “Vega” GPU archi­tec­tures in a seam­less­ly-inte­gra­ted SoC solu­ti­on that sets a new stan­dard for next-gene­ra­ti­on embedded designs.

“With the AMD Ryzen Embedded pro­ces­sors, our goal is to pro­vi­de cus­to­mers with the seam­less com­pu­te power nee­ded for desi­gners to achie­ve new levels of ver­sa­ti­li­ty and effi­ci­en­cy for embedded com­pu­ting,” said Ste­phen Turn­bull, direc­tor of pro­duct manage­ment and busi­ness deve­lo­p­ment, Embedded Solu­ti­ons, AMD. “We are exci­ted to see SAPPHIRE use the AMD Ryzen Embedded pro­ces­sors to deli­ver inno­va­ti­ve pro­ducts, such as the BP-FP5 and NP-FP5 embedded boards, deli­ve­ring a sta­ble balan­ce of low power con­sump­ti­on and opti­mi­zed per­for­mance for the embedded markets.”


Tur­bo Char­ged Mini PC
Sim­ply NUC the lea­ding spe­cia­list of NUC-based mini-com­pu­ter sys­tems is announ­cing an exten­si­on of their line of long-life mini-com­pu­ter pro­duct line based on SAPPHIRE embedded mother­boards at Embedded World 2020. Sim­ply NUC will launch three new fami­lies. The­se include Post Oak based on the BP-FP5 mother­boards powered by AMD Ryzen™ Embedded V1605B and R1606G Pro­ces­sor APUs, Red Oak based on the NP-FP5 mother­boards with AMD Ryzen™ Embedded R1505G and R1305G Pro­ces­sor APU ver­si­ons and Ever­green a more cost-effec­ti­ve solu­ti­on based on the BP GX424CC-LC2 motherboard.

Sim­ply NUC Post OAK

Spe­ci­fi­ca­ti­ons:

SAPPHIRE Model BP GX424CC-LC2 NP-FP5V BP-FP5V
Form Fac­tor 4x4 4″ x 4″ 4″ x 4″
CPU AMD Embedded G‑series
GX-424CC SOC		 AMD Ryzen™ Embedded V1000/R1000 AMD Ryzen™ Embedded V1000/R1000
TDP 25W Max. 25W Max. 25W
Coo­ler Active/Passive Acti­ve Acti­ve
Sys­tem Memory

DDR3 SO-DIMM

 DDR4 SO-DIMM (ECC/Non ECC) DDR4 SO-DIMM (ECC/Non ECC)
1x DDR3-1866 SO-DIMM, Max. 16GB (Non-ECC) 2x DDR4-Up to 2400 Max. 32GB (Right angle) 2x DDR4-Up to 2400, Max. 32GB
Exter­nal I/O
Edge
Connectors		 Dis­plays 2 x HDMI 2 x mini-DP1.4 2 x DP1.4 + 1 x HDMI 2.0
Ether­net 1 x Giga­bit Ethernet 1 x RJ-45, 1GbE 2x RJ-45, 1GbE
COM N/A N/A N/A
Audio Audio out Jack Com­bo Mic In/Audio out Jack (Front) Com­bo Mic In/Line out Jack (Front)
USB 2 x USB 2.0
2 x USB 3.0		 2 x USB3.1 + 2 x USB2.0 (Front) 1 x USB3.1(Front) + 2 x USB3.1
Inter­nal I/O
Headers		 COM 1 x (2 x 5) hea­der — RS232 N/A 1 x (2 x 5) hea­der– RS232/422/485 (Jum­per­less)
Front Panel 1 x (2 x 5) header 1 x (2 x 5) header 1 x (2 x5) header
Audio N/A N/A N/A
USB N/A 1x (2 x 4) hea­der sup­ports 1 xUSB2.0 1x (2 x 5) hea­der sup­ports 2 xUSB2.0
Others N/A N/A SATA PWR 1 x 4 pins
Secu­ri­ty TPM N/A N/A Infi­ne­on SLB9670 TPM2.0 on board
Chas­sis N/A N/A N/A
Power DC 12–19V, 1 x DC Power Jack 12 ~ 19V DC power jack 12 ~ 19V DC power jack
2x1 power header N/A N/A
Expan­si­on Slots 1x M.2 (Key M,2280) with PCIe x4 and SATA for SSD 1x M.2 (Key M, 2242/2280) with PCIe x4 and SATA for SSD 1x M.2 (Key M, 2242/2260) with PCIe x4 and SATA for SSD
1x M.2 (Key E, 2230) with PCIe x1 and USB2.0 for Wireless 1x M.2 (Key E, 2230) with PCIe x1 and USB2.0 for Wireless 1x M.2 (Key E, 2230) with PCIe x1 and USB2.0 for Wireless
N/A N/A 1 x SATA3 (6.0 Gb/s) + 1 x SATA Power

Why SAPPHIRE Embedded Solutions?

SAPPHIRE Tech­no­lo­gy is desig­ning and deli­ve­ring pro­ducts from its Embedded Sys­tems Busi­ness Unit, tar­ge­ting gra­phics inten­si­ve embedded sys­tem designs and small for­mat com­pu­ting solu­ti­ons for a wide ran­ge of applications.

SAPPHIRE’s inno­va­ti­on in design and exper­ti­se in manu­fac­tu­ring enables it to deli­ver a ran­ge of stan­dard and cus­tom solu­ti­ons for the embedded mar­ket. SAPPHIRE is clo­se­ly ali­gned with AMD for its embedded solu­ti­ons and exclu­si­ve­ly uses AMD tech­no­lo­gy at the core of its embedded gra­phics and com­pu­ting solutions.

With its long histo­ry in gra­phics, SAPPHIRE is deve­lo­ping and pro­du­cing uni­que pro­ducts for the visu­al embedded mar­ket, inclu­ding mul­ti-out­put add-in gra­phics cards and modu­les as well as mother­boards fea­turing on-board mul­ti-out­put dis­play capa­bi­li­ty. The­se solu­ti­ons tar­get appli­ca­ti­ons with high reso­lu­ti­on and mul­ti-dis­play requi­re­ments such as Digi­tal Signage, Gam­ing Machi­nes, Video Sur­veil­lan­ce and HD Mul­ti-Dis­plays for infor­ma­ti­on systems.

The SAPPHIRE Embedded BU can also deli­ver a num­ber of main­board solu­ti­ons based on the latest APU (Acce­le­ra­ted Pro­ces­sing Unit) tech­no­lo­gy from AMD. The APU com­bi­nes a mul­ti-core CPU with on-chip gra­phics and con­trol cir­cuit­ry to allow powerful small for­mat com­pu­ting solu­ti­ons to be imple­men­ted. SAPPHIRE offers a broad ran­ge of mini-ITX mother­boards with enhan­ced on-board capa­bi­li­ty as well as cus­tom form fac­tors and fea­tures spe­ci­fi­cal­ly desi­gned for embedded mar­kets. For appli­ca­ti­ons whe­re space is at a pre­mi­um, SAPPHIRE offers high­ly inte­gra­ted solu­ti­ons based on the latest AMD Embedded technology.
